AUTOMATIC LASER CONTROL

MOBA LASER SYSTEMS

CB.D3.CAN RECEIVING SYSTEM

The CB.D3 provides the control layer for automatic laser-based blade positioning. It takes the receiver reference and interfaces with the machine’s hydraulic system so the blade can respond automatically, reducing the repeated manual corrections required to stay on the intended grade or level.

key capabilities

  • Compatible with proportional or on/off hydraulic valves
  • Three accuracy settings
  • Can be integrated with an elevating mast
  • Large LCD, die-cast aluminum housing and compatibility with MOBA laser receivers, slope and ultrasonic sensors

AUTOMATIC LASER CONTROL

MOBA LASER SYSTEMS

DUO3.CAN RECEIVING SYSTEM

For grading attachments that use two laser receivers, the DUO3 provides the control between the receiver signals and the machine hydraulics. It is designed for applications where both sides of the blade need to respond to the laser reference, helping automate repeated blade-height corrections while the operator runs the machine.

key capabilities

  • Dual-control configuration for two-receiver applications
  • Compatible with proportional or on/off hydraulic valves
  • User adjustable accuracy settings
  • Supports elevating-mast integration and works with MOBA laser receivers, slope and ultrasonic sensors

VISUAL LASER RECEIVER

MOBA LASER SYSTEMS

LASERGUIDE MINI R.45.TC PRO

The R.45.TC PRO builds on the straightforward visual guidance of the R.45.TC and adds connectivity for remote in-cab display and setup options. It gives operators a clear laser reference at the machine while supporting applications that benefit from CAN or Bluetooth integration.

key capabilities

  • Automatic tilt compensation
  • Bluetooth and CAN connectivity
  • Remote in-cab display capability
  • 7.5 in receiving length; battery or external 12–24 VDC power

VISUAL LASER RECEIVER

MOBA LASER SYSTEMS

LASERGUIDE MINI R.45.TC

The R.45.TC brings the laser reference directly to the machine so the operator can see whether the attachment is high, low or on grade without repeatedly stopping to check elevation. Built-in tilt compensation automatically corrects for boom-angle changes, helping maintain a more dependable reference while the machine moves.

key capabilities

  • Automatic tilt compensation
  • Integrated magnetic clamp for quick mounting
  • Fully waterproof, all-metal construction
  • 7.5 in receiving length with operating range up to 1,970 ft

GRADE & LEVEL LASERS

MOBA LASER SYSTEMS

ROTEC LS.RH

ROTEC LS.RH is a compact horizontal self-leveling laser for construction and leveling work where crews need a dependable reference without a complicated setup. Its rugged housing, electronic self-leveling and field-ready power options make it a practical everyday laser for demanding sites.

key capabilities

  • Automatic horizontal self-leveling
  • Red laser beam with up to 1,970 ft radius operating distance using a hand-held receiver
  • Levelling accuracy of ±1.5 mm at 98 ft
  • IP55 protection with rechargeable or alkaline battery options

GRADE & LEVEL LASERS

MOBA LASER SYSTEMS

VISION 2N AUTOSLOPE / AUTOSLOPE ALIGN

The Vision 2N Autoslope is designed for grade work where maintaining the intended slope matters throughout the job. It electronically monitors the laser plane and automatically corrects for mechanical or thermal changes, reducing the need to stop and reset the reference.

key capabilities

  • Automatic dual-axis slope adjustment up to ±15%
  • Electronic monitoring and correction of the laser plane
  • Working range up to 4,920 ft radius
  • Autoslope Align variant adds automated alignment capability

GRADE & LEVEL LASERS

MOBA LASER SYSTEMS

VISION 2N / 2N ALIGN

The Vision 2N is built for applications that need both horizontal and vertical grade reference, including slope and alignment work. The 2N Align version adds automated alignment with the TE 90 ALIGN receiver, giving crews a more efficient setup when line and grade both matter.

key capabilities

  • Horizontal/vertical dual-grade operation
  • Monitored laser plane with manual slope, slope adjustment up to ±10%
  • Working range up to 2,300 ft radius
  • 2N Align supports automated alignment with TE 90 ALIGN

GRADE & LEVEL LASERS

MOBA LASER SYSTEMS

VISION 1N GRADE LASER

The Vision 1N provides a monitored laser reference for construction grading, site preparation and other work where crews need a dependable plane across the jobsite. It keeps the setup practical while helping protect against false readings when operating conditions change.

key capabilities

  • Monitored horizontal laser plane
  • Manual slope capability, slope adjustment up to ±10%
  • Working range up to 2,300 ft radius
  • Illuminated LCD display and laser-beam masking function
